China FTTH box for 12 SC,FC,LC adaptor

K&M's Fiber Termination Box(FTB) is mounted to in&out side wall of building or pole to distribute and connect  optical cable for distribution of subscriber

Fiber optic splitter modular box
  • Fiber optic splitter modular box
  • Fiber optic splitter modular box
  • Fiber optic splitter modular box
  • Fiber optic splitter modular box
  • Fiber optic splitter modular box
  • Product Orgin:

    Shenzhen China
  • Brand:

    K&M
  • Item NO.:

    KDMFTB12A
  • Shipping Port:

    Shenzhen/hk
  • Payment:

    TT/WU
  • Color:

    Gray
  • Lead Time:

    two weeks
Contact Now
  • Features & Benefits


FTTH FIBER OPTIC TERMINATION BOX

Fiber Optic Termination Box is a rugged, low profile interconnection unit suitable for all Fiber Optic and FTTx application, specially designed for residential use and it is applicable for large business premises

 Features

  • Indoor/Outdoor type

  • Nonmetallic material

  • Compacted wall mount type

  • Simple and clearly arranged incoming and outgoing cable management

  • Higher fiber count capacity box is available upon request

  • Easy maintenance ,easy access with front door

  • Support both mechanical and fusion splicing

  • Low cost solution with high protection for the terminated fibers

  • IP55 rated for outdoor applications

  • Customized design product is available upon request

  Applications

  • FTTX Systems

  • PON Networks

  • Fiber Optic Termination

  • CATV

 Specification

  • Wall Mounted termination box for indoor/ourdoor use
  • Up to 24 Fiber capacity  LC Duplex

  • Available for FC,SC,LC Simplex Adaptors  12 Fiber,LC duplex 24 Fiber

 Dimensions

Description

FTB12ASC-SX/12LC-DX

Dimensions (WxDxH)

290x250x90mm

Splice Capacity

Max.12 SC/FC/LC

Cable Port

In:2-port(Φ8~12mm)/Out:12-port (normal cable)

Color

Ivory/White

Main Body Material

Plastic: ABS+PC

Installation Type

Wall /Pole Type Outdoor
