K&M's Fiber Optic Pigtails are manufactured with either multimode or single-mode fibre and terminated with a range of connectors including SC, SC/APC, LC, LC/APC, FC, FC/APC, ST and MTRJ. Other connector types are also available upon request.
Product Orgin:
Shenzhen ChinaBrand:
K&MItem NO.:
KDM12SM-LCA-1MShipping Port:
Shenzhen/hkPayment:
TTPrice:
$7/PcsMarket Price:
$12Price Range:
500-1000/7$Color:
12 color-codedLead Time:
7-15 days
12 Fibers LC APC Single-Mode Color-Coded Fiber Optic Pigtail, Unjacketed
Our LC enhanced Patch Cords supplied with a short boot are ideal for high density applications with tight space requirements. These patch cords have the added benefit of being supplied with reduced bend sensitivity ITU-T G657 singlemode optical fibre which exhibit much lower optical power loss under bend conditions while remaining compatible with conventional cabling. LC short boot patch cords are designed to meet IEC and BS EN requirements.
Features
We provide the broadest choices of Simplex/Duplex including high-grade FC, SC, ST, LC, MTRJ, E2000 and MU with Ultra-polished (UPC), Angle-Polished (APC) connectors or other polish requirement. Our daily output is 11500 pieces. We keep sufficient storage of the most common types of patch cords for instantly delivery. With this service, you no longer suffer from long term waiting.
For special requests on test reports or other specifications, please contact us.
Applications
Building interconnections (campus LAN)
Trucking lines direct to telecommunications closet
Fiber patch panels within communications closets
Links between electronic equipment and fiber panels
Ordering Information
Item |
Single mode UPC |
Single mode APC |
Multimode |
Insertion Loss |
≤ 0.2dB (typical) 0.3dB(Max) |
≤ 0.2dB (typical) 0.3dB(Max) |
≤ 0.2dB (typical) 0.3dB(Max) |
Return Loss |
≥50 dB |
≥60 dB |
≥25 dB |
Durability |
Min 500 mate times |
||
Operating Temperature |
-40℃ to+85℃ |
||
Cord length |
Customized |
||
Optical fiber |
1-12 fiber |
|
