Product Orgin:
Shenzhen ChinaBrand:
K&MItem NO.:
KDMSPP2-16-1809Shipping Port:
Shenzhen/hkPayment:
TT/LC/WUPrice:
$65/PcsMarket Price:
$70Price Range:
100-500/65$Color:
OptionalLead Time:
two weeks
PLC SPLITTER
K&M Planar Lightwave Circuit (PLC splitter) splitter is a type of optical power management device that is fabricated using silica optical waveguide technology. It features small size, high reliability, wide operating wavelength range and good channel-to-channel uniformity, and is widely used in PON networks to realize optical signal power splitting. We provide whole series of 1xN and 2xN splitter products that are tailored for specific applications.
Made of high quality steel sheet
Modularized design
Convenient for installation and maintenance
Low Insertion loss and PDL
High return loss (P/S Grade: 55/50 dB)
Directivity 55 dB
Compact Design
Wide Operating Wavelength: From 1260nm to 1650nm
Wide Operating Temperature: From -40°C to 85°C
1 & 2 input channel, and 4, 8, 16, 32 and 64 channel available
High Reliability and Stability
Telcordia GR-1209-CORE-2001 compliant
elcordia GR-1221-CORE-1999 compliant
RoHS compliant
FTTX Systems
PON/GPON/EON Networks
CATV Links
Optical Signal Distribution
Specification
1:N PLC Splitter Parameters |
1:2 |
1:4 |
1:8 |
1:16 |
1:32 |
1:64 |
2:4 |
2:8 |
2:16 |
2:32 |
Operating Wavelength (nm) |
1260~1650 |
|||||||||
Insertion Loss (dB)(P/S Grade) |
3.8/4.0 |
7.1/7.3 |
10.2/10.5 |
13.5/13.7 |
16.5/16.9 |
20.5/21.0 |
7.6 |
11.0 |
14.5 |
17.5 |
Loss Uniformity (dB) |
0.4 |
0.6 |
0.8 |
1.2 |
1.5 |
2.0 |
1.2 |
1.5 |
2.0 |
2.5 |
Polarization Dependent Loss(dB) |
0.2 |
0.2 |
0.2 |
0.25 |
0.3 |
0.35 |
0.3 |
0.3 |
0.4 |
0.4 |
*The above specification without connector. With connectors should add 0.3dB.
Ordering Information
xx: Number of output channels yy: Connector type (SC, LC, …) z: Connector surface type (U=UPC, A=APC) a: Fiber type (A=G657A, D=G652D) |
xx: Number of output channels yy: Connector type (SC, LC, …) z: Connector surface type (U=UPC, A=APC) a: Fiber type (A=G657A, D=G652D) |
Ordering Sample: KMSPP132SCAA (1:32 splitter, 19” panel type, SC connector, APC, G657A)
