Armored Single Jacket Loose Tube Cable

Acting as the backbone for most of today’s fiber based systems, stranded fiber optic cables play a critical role in the high speed network. KDM’s Non-Armored Loose Tube fiber optic

cables are designed to provide high fiber counts with the flexibility and versatility required

for today’s most demanding installations. With fiber counts up to 576 and S-Z strand

designs for easy mid-span access, KDM’s cables comply with EIA/TIA, REA/RUS PE-90 and

GR-20. Industry standard designs combined with innovative technologies, such as a dry

core product, yield a world class cable that will support today’s and tomorrow’s

technological needs.

Loose Tube Stranding Cable
  • Loose Tube Stranding Cable
  • Product Orgin:

    Shenzhen,China
  • Brand:

    K&M
  • Item NO.:

    KDM-lOOSE Tube Stran
  • Shipping Port:

    ShenZhen/HK
  • Payment:

    T/T
  • Price:

    $29.8/100M
  • Market Price:

    $32
  • Price Range:

    500-1000/29.8$
  • Color:

    As your requirement
  • Lead Time:

    2 Weeks after remittance
Contact Now
  • Features & Benefits

Specifications:

  • OFNG-LS Listed, CSA-FT4, IEEE1202 and UL 1685
  • Meets requirements of NFPA 130 and NFPA 502 for use in fixed guideway transit systems and road tunnels
  • ICEA S-104-696
  • CSA 22.2 No. 230 and 232
  • Fluid immersion testing per ASTM D412
  • Sunlight Resistant Jacket
  • Oil Res II compliant Jacketing System
  • Zero Halogen Per MIL PRF 85045

Features:

  • Gel-Free buffer tubes
  • Fiber Range 12-288
  • Suitable for direct burial and tray installations per UL 1277
  • Increased tensile load rating
  • 2X Crush Resistance compared to standard fiber optic cables
  • 2X Cold Impact Resistance compared to standard fiber optic cables
  • Self-supporting capability (contact factory for system design support)

Applications Network Connectivity for:



  • Long Haul Networking
  • Building Interconnections (Campus LAN)
  • Trunking Lines Direct to Telecommunications Closet
  • Local Loop
  • Distance Learning
  • Distribution
  • Intrabuilding Backbone



Temperature Specifications:


TEMPERATURE RANGE
INSTALLATION -30ºC to +70ºC
OPERATING  -40ºC to +70ºC
STORAGE -40ºC to +75ºC



Mechanical:

Parameter  Value
Crush  440N/CM
Cold Impact 8.8 N*m
Tensile
Installation
1,000 lbs (4,450N)
Operational 400 lbs (1,780N)


Cable Components:

Fiber Specification:

Fiber Type Maxmum Attenuation
(DB/KM)
Overfill Launch Min.Bandwidth(MHz•km) Gigabit Ethernet Min.
Link Distance (meters)
850NM 1300NM 1310NM 1550NM 850NM 1300NM 850NM 1300NM
(6) 62.5/125 GIGA-Link™ 300 3.5 1.2 N/A N/A 200 600 300 550
(8) 62.5/125 GIGA-Link™ 1000 3.5 1.2 N/A N/A 350 600 500 1000
(5) 50/125 GIGA-Link™ 600 2.9 0.9 N/A N/A 500 600 600 600
(7) 50/125 GIGA-Link™ 2000 2.9 0.9 N/A N/A 500 800 750 2000
(L) 50/125 Laser-Link 300 2.9 0.9 N/A N/A 1500 500 900 550
(9) Single-mode N/A N/A 0.35 0.25 N/A N/A N/A 5000
(K) SM Futureguide SR-15e
 Bend Insensitive
N/A N/A 0.35 0.25 N/A N/A N/A 5000

Gigabit Ethernet Minimum Link Distances are based on "bandwidth"/modal dispersion constraints. Actual link distances may be constrained by attenuation, depending on specific loss budget.


Ordering Information:

Fiber Count Number Of Tubes/Fibers Nominal Diameter Nominal Weight Maxmum Tensile Load Minimum Bend Radius
LBS(N) Inches(CM)
Inches MM LBS/1,000FT KG/KM Short Term Long Term Short Term Long Term
6 1w/6 (4 fillers) 0.41 10.5 56 83 600 (2670) 200 (890) 8.2 (21) 4.1 (11)
12 1w/12 (4 fillers) 0.41 10.5 56 84 600 (2670) 200 (890) 8.2 (21) 4.1 (11)
18 1w/12,1w/6(3 fillers) 0.41 10.5 57 85 600 (2670) 200 (890) 8.2 (21) 4.1 (11)
24 2w/12 (3 fillers) 0.41 10.5 57 85 600 (2670) 200 (890) 8.2 (21) 4.1 (11)
30 2w/12,1w/6 (2 fillers) 0.41 10.5 58 86 600 (2670) 200 (890) 8.2 (21) 4.1 (11)
36 3w/12 (2 fillers) 0.41 10.5 58 86 600 (2670) 200 (890) 8.2 (21) 4.1 (11)
48 4w/12 (1 fillers) 0.41 10.5 59 87 600 (2670) 200 (890) 8.2 (21) 4.1 (11)
60 5w/12 (no fillers) 0.41 10.5 60 89 600 (2670) 200 (890) 8.2 (21) 4.1 (11)
72 6w/12 (no fillers) 0.45 11.5 71 106 600 (2670) 200 (890) 9.0 (22) 4.5 (11.5)
84 7w/12 (1 fillers) 0.52 13.3 90 135 600 (2670) 200 (890) 10.4 (27) 5.2 (14)
96 8w/12 (no fillers) 0.52 13.3 91 136 600 (2670) 200 (890) 10.4 (27) 5.2 (14)
108 9w/12 (1 fillers) 0.59 15.1 117 174 600 (2670) 200 (890) 11.8 (31) 5.9 (16)
120 10w/12 (no fillers) 0.59 15.1 118 175 600 (2670) 200 (890) 11.8 (31) 5.9 (16)
132 11w/12 (1 fillers) 0.67 17 147 219 600 (2670) 200 (890) 13.4 (34) 6.7 (17)
144 12w/12 (no fillers) 0.67 17 148 220 600 (2670) 200 (890) 13.4 (34) 6.7 (17)
216 18w/12 (no fillers) 0.69 17.4 150 224 600 (2670) 200 (890) 14.0 (35) 6.9 (18)
188 24w/12 (no fillers) 0.79 20.1 202 301 600 (2670) 200 (890) 17.3 (41) 7.9 (21)
432 24w/18 (no fillers) 0.87 22 242 360 600 (2670) 200 (890) 17.3 (44) 8.7 (22)
576 24w/24 (no fillers) 1 25.3 319 475

600 (2670)

200 (890) 20.1 (51) 10.2 (26)

Note: Diameter and weight subject to change without notice

Fiber Types – Replace asterisk, in AFL number with number corresponding to desired

fiber type below.

5 = 50/125 µm multimode GIGA-Link™ 600

7 = 50/125 µm multimode GIGA-Link™ 2000

6 = 62.5/125 µm multimode GIGA-Link™ 300

8 = 62.5/125 µm multimode GIGA-Link™ 1000

L = 50/125 µm multimode Laser-Link™ 300

9 = Single-mode

Q = Non-zero dispersion-shifted single-mode

K = SM Futureguide SR-15e Bend Insensitive
