1M 12 Fibers LC/UPC 10G 50/125 OM3 Multi-Mode Bunch Fiber Optic Pigtail - 0.9mm PVC Jacket

Compliant to Telcordia, EIA/TIA standards for Factory Terminations

1M 12 Fibers LC/UPC 10G 50/125 OM3 Multi-Mode Bunch Fiber Optic Pigtail - 0.9mm LSZH Jacket
  • 1M 12 Fibers LC/UPC 10G 50/125 OM3 Multi-Mode Bunch Fiber Optic Pigtail - 0.9mm LSZH Jacket
  • 1M 12 Fibers LC/UPC 10G 50/125 OM3 Multi-Mode Bunch Fiber Optic Pigtail - 0.9mm LSZH Jacket

  • Product Orgin:

    shenzhen China

  • Brand:

    K&M

  • Item NO.:

    KDM12OM3-LCU-1M-LSZH

  • Shipping Port:

    shenzhen/hk

  • Payment:

    TT/WU

  • Price:

    $12/Pcs

  • Market Price:

    $16

  • Price Range:

    500-1000/12$

  • Color:

    Aqua

  • Lead Time:

    7-14 days
Contact Now
  • Features & Benefits

1M 12 Fibers LC/UPC 10G 50/125 OM3 Multi-Mode Bunch Fiber Optic Pigtail

Fiber pigtails are a great solution for fusion splicing inside of a fiber optic enclosure. The bunch fan-out fiber pigtails come with a partial outer jacket to help protect the tight buffer fibers from being damaged. If space is a premium, the outer jacket can easily be removed, allowing the pigtails to have a tighter bend radius and take up less space.


Connector A LC Connector B Unterminated
Fiber Category 50/125μm OM3 Multimode Jacket Color Aqua
Cable Diameter 0.9mm Jacket Material LSZH
Total Length 1M Breakout Length 0.3M
Fiber Count 12 Polish UPC
Wavelength 850nm and 1310nm Durability >1000 Times
Insertion loss ≤0.3dB Interchangeability ≤0.2dB
Return loss ≥50dB Vibration ≤0.2dB
Operating temperature -40~75°C Storage temperature -45~85°C

Key Features and Applications

  • Low insertion loss, Low back reflection loss
  • Flexible and easy to strip fibre buffering
  • Identifiable fibre buffer colours under all lighting conditions
  • Reduces installation time
  • Avoids incorrect patching by possible fiber flipping
  • Data Centres, premise installations
  • Telecomunication networks
  • Local area networks(LAN)
  • Wide area networks(WAN)
  • Indoor Applications
