Milky MM Duplex SC\SC Adaptor

Adaptor SC MM Duplex
  • Adaptor SC MM Duplex

  • Product Orgin:

    Shenzhen China

  • Brand:

    K&M

  • Item NO.:

    KDMA-SCU-MM-DX

  • Shipping Port:

    shenzhen/hk

  • Payment:

    TT

  • Price:

    $0.25/Pcs

  • Market Price:

    $0.4

  • Price Range:

    1000-5000/0.25$

  • Color:

    Milky

  • Lead Time:

    7 days
Contact Now
  • Features & Benefits
SC DX MM Fiber Optic Adaptor

DESCRIPTION:

Fiber Optic Supply supplies a full line of fiber optic adapters for every application including flanged, threaded, metal, composite and hybrid or plug varieties. The adapters are available in simplex or duplex configurations with a zirconia or Phosphor Bronze sleeve for high precision alignment. The hybrid fiber optic adaptors allow users to convert from one connector type to another. These adaptors are comprised of a polymer outer body and inner assembly fitted with a precision alignment mechanism. These adaptors are precision made and manufactured to demanding specifications. The combination of a ceramic /phosphor bronze alignment sleeves and precision molded polymer housing provides consistent long-term mechanical and optical performance.

  • Product Name:                                      SC DX MM Adapter
  • Item Code:                                            SC MM
  • Category:                                              Networking & Communications
  • Package Size:                                       15 *15 * 10( cm ) - 100pieces

  • Gross Weight/Package:                       0.01 ( kg)

  •  Adapter Types:                                    Female-Female, Hybrid and Male-Female.

  • Typical Insertion Loss :                        ≤0.2dB
  • Operating Temperature :                       -40 ℃ ~+85 ℃

KEY FEATURES:

  1. Compliant with : ANSI , Bellcore, TIA/EIA standards .
  2. Low insertion and high return loss .
  3. Excellent repeatability and changeability .
  4. Simplex and duplex available.


APPLICATIONS:

1.Networking:

  • Computer Connections - LAN/WAN
  • Fibre Channel and Gigabit Ethernet
  • Networking equipment
  • Routers
  • Servers
  • Storage

2.Telecommunications:

  • ATM testing
  • Active device termination
  • CATV
  • Cross connects
  • Device terminations
  • FTTX connections
  • Fibre Channel testing
  • Hubs
  • Instrumentation - test equipment
  • Optical switches
  • Premise installations
