Product Orgin:
Shenzhen,ChinaBrand:
K&MItem NO.:
KDMGYFTYCABLEShipping Port:
ShenZhen/HKPayment:
T/TColor:
As your requirementLead Time:
2 Weeks after remittance
Outdoor GYFTY SM Non-Metal 2-84 fiber Optic Cable
1 TECHNICAL SPECIFICATION
Fiber count |
2~30 |
32~36 |
38~60 |
62~72 |
74~84 |
|||
Loose Tube |
OD(mm): |
1.8±0.1 |
1.8±0.1 |
2.0±0.1 |
2.0±0.1 |
2.0±0.1 |
||
Material: |
PBT |
|||||||
Max fiber count/tube |
6 |
6 |
12 |
12 |
12 |
|||
Core unit |
6 |
6 |
6 |
6 |
7 |
|||
FRP/Coating(mm) |
1.8 |
1.8 |
2.0 |
2.0 |
2.0/2.7 |
|||
Water Blocking Material |
water-blocking compound |
|||||||
Sheath |
Thickness: |
Non. 1.5mm |
||||||
Material: |
PE |
|||||||
OD of cable (mm) |
8.4±0.2 |
8.4±0.2 |
9.0±0.2 |
9.0±0.2 |
9.7±0.2 |
|||
Net weight ( kg/km) |
56 |
61 |
60 |
60 |
68 |
|||
Fiber count |
86~96 |
98~108 |
110~120 |
122~132 |
134~144 |
|||
Loose Tube |
OD(mm): |
2.0±0.1 |
2.0±0.1 |
2.0±0.1 |
2.0±0.1 |
2.0±0.1 |
||
Material: |
PBT |
|||||||
Max fiber count/tube |
12 |
12 |
12 |
12 |
12 |
|||
Core unit |
8 |
9 |
10 |
11 |
12 |
|||
FRP/Coating(mm) |
2.5/3.4 |
2.5/4.0 |
3.0/4.7 |
3.0/5.3 |
3.0/6.0 |
|||
Water Blocking Material |
water-blocking compound |
|||||||
Sheath |
Thickness: |
Non. 1.5mm |
||||||
Material: |
PE |
|||||||
OD of cable (mm) |
10.4±0.2 |
11.0±0.2 |
11.7±0.2 |
12.3±0.2 |
13.0±0.2 |
|||
Net weight ( kg/km) |
80 |
90 |
103 |
113 |
125 |
|||
|
|
|
|
|
|
|
|
|
2. FIBER AND LOOSE BUFFER TUBE IDENTIFICATION
NO. |
1 |
2 |
3 |
4 |
5 |
6 |
7 |
8 |
9 |
10 |
11 |
12 |
Tube Color |
Blue |
Orange |
Green |
Brown |
Slate |
White |
Red |
Black |
Yellow |
Violet |
Pink |
Aqua |
NO. |
1 |
2 |
3 |
4 |
5 |
6 |
7 |
8 |
9 |
10 |
11 |
12 |
Fiber Color |
Blue |
Orange |
Green |
Brown |
Slate |
White/natural |
Red |
Black |
Yellow |
Violet |
Pink |
Aqua |
3. OPTICAL FIBER
3.1 Single Mode Fiber
LTEMS |
UNITS |
SPECIFICATION |
||
Fiber type |
|
G652D |
G657A |
|
Attenuation |
dB/km |
1310nm ≤ 0.36 1550nm ≤ 0.22 |
||
Chromatic Dispersion |
ps/nm.km |
1310nm≤ 3.5 1550nm≤ 18 1625nm≤ 22 |
||
Zero Dispersion Slope |
ps/nm2.km |
≤ 0.092 |
||
Zero Dispersion Wavelength |
nm |
1300 ~ 1324 |
||
Cut-off Wavelength (lcc) |
nm |
≤ 1260 |
||
Attenuation vs. Bending (60mm x100turns) |
dB |
(30mm radius,100ring )≤ 0.1 @ 1625nm |
(10mm radius,1ring)≤ 1.5 @ 1625nm |
|
Mode Field Diameter |
mm |
9.2 ± 0.4 at 1310nm |
9.2 ± 0.4 at 1310nm |
|
Core-Clad Concentricity |
mm |
≤ 0.5 |
≤ 0.5 |
|
Cladding Diameter |
mm |
125±1 |
125±1 |
|
Cladding Non-circularity |
% |
≤ 0.8 |
≤ 0.8 |
|
Coating Diameter |
mm |
245±5 |
245±5 |
|
Proof Test |
Gpa |
≥ 0.69 |
≥ 0.69 |
|
|
|
|
|
|
3.2 Multi Mode Fibers
LTEMS |
UNITS |
SPECIFICATION |
|||||||
62.5/125 |
50/125 |
OM3-150 |
OM3-300 |
OM4-550 |
|||||
Fiber Core Diameter |
μm |
62.5±2.5 |
50.0±2.5 |
50.0±2.5 |
|||||
Fiber Core Non-circularity |
% |
≤6.0 |
≤6.0 |
≤6.0 |
|||||
Cladding Diameter |
μm |
125.0±1.0 |
125.0±1.0 |
125.0±1.0 |
|||||
Cladding Non-circularity |
% |
≤2.0 |
≤2.0 |
≤2.0 |
|||||
Coating Diameter |
μm |
245±10 |
245±10 |
245±10 |
|||||
C0at-Clad Concentricity |
μm |
≤12.0 |
≤12.0 |
≤12.0 |
|||||
Coating Non-circularity |
% |
≤8.0 |
≤8.0 |
≤8.0 |
|||||
Core-Clad Concentricity |
μm |
≤1.5 |
≤1.5 |
≤1.5 |
|||||
Attenuation |
850nm |
dB/km |
3.0 |
3.0 |
3.0 |
||||
1300nm |
dB/km |
1.5 |
1.5 |
1.5 |
|||||
OFL |
850nm |
MHz﹒km |
≥160 |
≥200 |
≥700 |
≥1500 |
≥3500 |
||
1300nm |
MHz﹒km |
≥300 |
≥400 |
≥500 |
≥500 |
≥500 |
|||
The biggest theory numerical aperture |
/ |
0.275±0.015 |
0.200±0.015 |
0.200±0.015 |
|||||
|
|
|
|
|
|
|
|
|
|
5. Mechanical and Environmental Performance of the Cable
NO. |
ITEMS |
TEST METHOD |
ACCEPTANCE CRITERIA |
1 |
Tensile Loading Test
|
#Test method:IEC 60794-1-E1 -. Long-tensile load:600N -. Short-tensile load:1500N -. Cable length:≥50m |
-. Attenuation increment@1550nm:≤0.1dB -. No jacket cracking and fiber breakage |
2 |
Crush Resistance Test |
#Test method:IEC 60794-1-E3 -.Long load:300 N/100mm -.Short load:1000 N/100mm Load time:1 minutes |
-. Attenuation increment@1550nm:≤0.1dB -. No jacket cracking and fiber breakage |
3 |
Impact Resistance Test |
#Test method:IEC 60794-1-E4 -.Impact height:1m -.Impact weigh: 450g -.Impact point:≥5 -.Impact frequency:≥3/point |
-. Attenuation increment@1550nm:≤0.1dB -. No jacket cracking and fiber breakage |
4 |
Repeated Bending |
#Test method:IEC 60794-1-E6 -.Mandrel diameter:20D (D = cable diameter) -.Subject weight:15kg -.Bending frequency:30 times -.Bending speed:2s/time |
-. Attenuation increment@1550nm:≤0.1dB -. No jacket cracking and fiber breakage |
5 |
Torsion Test |
#Test method:IEC 60794-1-E7 -.Length:1m -.Subject weight:25kg -.Angle:±180 degree -.Frequency:≥10/point |
-. Attenuation increment@1550nm:≤0.1dB -. No jacket cracking and fiber breakage |
6 |
Water Penetration Test |
#Test method:IEC 60794-1-F5B -.Height of pressure head:1m -.Length of specimen:3m -.Test time: 24 hours |
-. No leakage through the open cable end |
7 |
Temperature Cycling Test |
#Test method:IEC 60794-1-F1 -.Temperature steps:+20℃、-40℃、+70℃、+20℃ -.Testing Time:24 hours/step -.Cycle index:2 |
-. Attenuation increment@1550nm:≤0.1dB -. No jacket cracking and fiber breakage |
8 |
Drop Performance
|
#Test method:IEC 60794-1-E14 -.Testing length:30cm -.Temperature range:70±2℃ -.Testing Time:24 hours |
-. No filling compound drop out |
9 |
Temperature |
Operating:-40℃~+60℃ Store/Transport :-50℃~+70℃ Installation -20℃~+60℃ |
5. FIBER OPTIC CABLE BENDING RADIUS
Static bending:≥10 times than cable out diameter
Dynamic bending:≥20times than cable out diameter
6. PACKAGE AND MARK
6.1 PACKAGE
Not allowed two length units of cable in one drum, two ends should be sealed,. Two ends should be packed inside drum, reserve length of cable not less than 3 meters.
