cat5e SFTP Lan cable/Solid Bare Copper Cat5e Lan cable

Application:

1000BASE-T Gigabit Ethernet

10BASE-T,100BASE-T Fast Ethernet(IEEE 802.3)

100vg-AnyLAN(IEEE 802.12),

155/622Mbps ATM

550MHz Broadband Video Voice,T1,ISDN



cat5e SFTP Lan cable/Solid Bare Copper Cat5e Lan cable K&M
  • Product Orgin:

    ShenZhen
  • Brand:

    K&M
  • Item NO.:

    K&M cat5e-cu
  • Shipping Port:

    ShenZhen/HK
  • Payment:

    T/T
  • Price:

    $35.386/Roll
  • Market Price:

    $40
  • Price Range:

    100-500/35.386$
  • Color:

    gray
  • Lead Time:

    Two weekends
Contact Now
  • Features & Benefits

-Electrical Performance

Spark Test:                                        850V ac

Dielectric Strength:                          2500Vdc/3 Seconds

Insulation Resistance Test:          Min.150MΩ/KM

Conductor Resistance:                  Max.9.38Ω/100m at 20

Resistance Unbalance:                 Max.5%

Capacitance Unbalance:               Max 330 PF/100M

Mutual Capacitance:                       Max.5600 PF/100M

Impedance:                                      722KHZ   102Ω±15%

                                                              1~123KHZ   100Ω±15%


-Standard Compliances:

All Category 5e Requirements as per ANSI/TIA/EIA,ISO/IEC,

and CENELEC EN Standards:

ANSI/TIA/EIA 568-B.2 CAT5e 2nd Edition ISO/IEC 11801 Class D

CENELEC EN 50173-1 IEC 61156-5,

CENELEC EN50288-2-1

Horizontal Cable Flame Retardancy is Verified According to IEC 60332-1



-Cable Date

Conductor:                                                 Solid bare copper

AWG:                                                           24

Conductor Dia(mm):                               0.51

Insulation:                                                 PE

Average thickness(±0.03mm):             0.20

Min point thickness:                                0.17

Insulation Dia(±0.03mm):                     0.91

Twisting Lay Length(mm)                    30 undemeath

Cabling Lay Length(mm):                     200 undemeath

Jacket:                                                       PVC

Average thickness(±0.03mm):            0.50

Min point thickness:                               0.43

Outer Dia(±1.0mm):                              5.1

Rip Cord:                                                 Yes

Weight Nom(kg/km) :                            32

Core color:                                              Blue-white/blue

                                                                     Orange-white/Orange

                                                                     Green-white/Green

                                                                     Brown-white/Brown



Electrical performance:

Frequency(MHz)

1MHz

4.0

8.0

10.0

16.0

20.0

25.0

31.25

62.5

100.0

125.0

Attenuation(dB/100 Meters at 20), Max

------

4.1*

5.8*

6.5*

8.2*

9.3*

10.4*

11.7*

17.0*

22.0*

25.0*

NEXT(dB),Min

65*

56*

51*

50*

47*

45*

44*

42*

38*

35*

34*

Power Sum (dB), Min

62*

53*

48*

47*

44*

42*

41*

39*

35*

32*

31*
