19'' or 21'' ETSI Open Rack

 ETSI Rack
  •  ETSI Rack
  •  ETSI Rack
  •  ETSI Rack
  • Product Orgin:

    Shenzhen China
  • Brand:

    K&M
  • Item NO.:

    KDM-16-1860
  • Shipping Port:

    Shenzhen/hk
  • Payment:

    TT/LC/WU
  • Price:

    $250/Pcs
  • Market Price:

    $300
  • Price Range:

    100-500/250$
  • Color:

    Gray
  • Lead Time:

    two weeks
Contact Now
  • Features & Benefits



21'' ETSI Open Rack



 Features

  • Compliance with ETSI rack-mount 21 inch and compatible with 19 inch.

  • Cable Clamp Rails Height-adjustable for cable sheath & strength member clamping, with cable routing at the sides of the rack

  • 21’ installation rail front and rear adjustable range for 150mm.

  • The base thickness 2.0mmpost rail thickness 1.5mm.

  • Maximum loading capacity 200Kg

  • Surface finish to be painting color RAL7032

  • The rack is disassemble one but shipped we propose in fully constructed.

  • Whole front operation as lead-in, striping and dispatching for optical cables.

  • Management of patch cord can choose fiber storage box or frame according to actual needs.

  • Modular design, convenience for install.

  • Structure of the frame is open type.

  • Protective connector for striping ribbon fiber make sure the protection of bare fiber ,the fixation and grounding of optical cable more completely .

  • Can install optical splitter module and attenuator and some value-added module.

  • The cable can be lead in top or bottom as required.

  • Top side has dustproof device, Bottom side has removable plate.

 Dimensions





Technical Specifications
  • Operation temperature:         -5°C ~ +40°C
  • Storage temperature:      -25°C ~ +55°C

  • Relative humidity:                ≤ 85% (+30°C)

  • Atmospheric pressure:   70 kPa ~ 106 kPa

  •
