Product Orgin:
Shenzhen ChinaBrand:
K&MItem NO.:
GJS-H001Shipping Port:
Shenzhen/hkPayment:
TTPrice:
$25/PcsMarket Price:
$45Price Range:
500-1000/25$Color:
BlackLead Time:
two weeksGJS-H001 Fiber splice closure
The fiber splice closure is applicable to termination of branching downstream optical cable in PON optical communication network。Over FTTX network,fiber splice closure is used for end A/B access of optical cable ,splicing of low-capacity single-fibers,lead-out and fixation of mult-fiber access cables。
Technical specifications
Compliance with YD 814.1-2004 and YD 814.2-2005
l Complete bend radius control, the bend radius >30mm
l Flammability: GB5169.7 Experiment A
Operating temperature : -40℃~+60 ℃
Relative humidity: ≦ 85% (+30℃)
Atmospheric pressure: 70~106kP
Storage temperature: -25℃~+60 ℃
Features:
l Installation modes: overhead-mounted,burry-mounted,wall-mounted,pole-mounted,manhole-mounted;
l Aging-resistant plastic ,and corrosion-resistant metalworking subassemblies
l Fast and easy sealing of closure body and optical cable openings
l Perfect optical route design to ensure bend radius of fibers ,large fiber storage area
l Optical splice tray ,applicable to ribbon and bundle cable, random configuration under the maximum capacity
l Large storage space for splice tray with greater than 90°overturn angel,easy for maintenance and expansion
l Configurable with grounding device and valve
l Service life not less than 20 years
l IP degree:IP68
Ordering information
Product Name |
Ordering code |
Model |
Dimension |
Splice capacity (fiber) |
Cable Inlet |
Remarks |
|
Bundle/Ribbon |
|||||||
Horizontal fiber splice closure
|
Body |
080103800 |
GJS-H001 |
450×220×160 |
192/576 |
4-inlet 4-outlet |
Inlet cable diameter: Ф16-Ф23 4 RJ-J201(single)/ 4 RJ-J202(single)/ 4 RJ-J215(ribbon)4 RJ-J216(ribbon) |
Splice stry |
080103030 |
RJ-J201 |
\ |
12 |
\ |
\ |
|
Splice stry |
080103040 |
RJ-J202 |
\ |
24 |
\ |
\ |
|
Splice stry |
080103790 |
RJ-J215 |
\ |
24(4-fiber ribbon)/ 36(6-fiber ribbon)/ 48(8-fiber ribbon)/ 72(12-fiber ribbon)/ |
\ |
\ |
|
Splice stry |
080103800 |
RJ-J216 |
\ |
24(4-fiber ribbon)/ 36(6-fiber ribbon)/ 48(8-fiber ribbon)/ 72(12-fiber ribbon)/ |
\ |
\ |
