Fiber Splice Horizantal closure 144 Cores

The fiber splice closure is applicable to termination of branching downstream optical cable in PON optical communication network。Over FTTX network，fiber splice closure is used for end A/B access of optical cable ，splicing of low-capacity single-fibers，lead-out and fixation of mult-fiber access cables

Fiber Splice Online closure 144 cores
  • Fiber Splice Online closure 144 cores
  • Fiber Splice Online closure 144 cores

  • Product Orgin:

    Shenzhen China

  • Brand:

    K&M

  • Item NO.:

    KDMFHC-144C

  • Shipping Port:

    Shenzhen/hk

  • Payment:

    TT

  • Price:

    $15/Pcs

  • Market Price:

    $35

  • Price Range:

    500-1000/15$

  • Color:

    Black

  • Lead Time:

    two weeks
Contact Now
  • Features & Benefits

GJS-001  Fiber splice closure

The fiber splice closure is applicable to termination of branching downstream optical cable in PON optical communication network。Over FTTX network，fiber splice closure is used for end A/B access of optical cable ，splicing of low-capacity single-fibers，lead-out and fixation of mult-fiber access cables

Technical specifications

Compliance with YD 814.1-2004 and YD 814.2-2005

Physical performance

l  Complete bend radius control， the bend radius >30mm

l  Flammability: GB5169.7 Experiment A

Ambient condition

 Operating temperature : -40℃~+60 ℃

 Relative humidity: ≦ 85% （+30℃）

 Atmospheric pressure： 70~106kP

 Storage temperature: -25℃~+60 ℃

 Features:

l  Installation modes: overhead-mounted，burry-mounted，wall-mounted，pole-mounted，manhole-mounted;

l  Aging-resistant plastic ，and corrosion-resistant metalworking subassemblies

l  Fast and easy sealing of closure body and optical cable openings

l  Perfect optical route design to ensure bend radius of fibers ，large fiber storage area

l  Optical splice tray ，applicable to ribbon and bundle cable， random configuration under the maximum capacity

l  Large storage space for splice tray with greater than 90°overturn angel，easy for maintenance and expansion

l  Configurable with grounding device  and valve

l  Service life not less than 20 years

l  IP degree：IP68



Ordering information

Product Name

Ordering code

Model

Dimension

Splice capacity

(fiber)

Cable Inlet

Remarks

Bundle/Ribbon

Horizontal fiber splice closure



Body

080103800

GJS-H001

450×220×160

192/576

4-inlet

4-outlet

Inlet cable diameter:

Ф16-Ф23

4 RJ-J201(single)/ 4 RJ-J202(single)/ 4 RJ-J215(ribbon)4 RJ-J216(ribbon)

Splice stry

080103030

RJ-J201

\

12

\

\

Splice stry

080103040

RJ-J202

\

24

\

\

Splice stry

080103790

RJ-J215

\

24(4-fiber ribbon)/ 36(6-fiber ribbon)/ 48(8-fiber ribbon)/ 72(12-fiber ribbon)/

\

\

Splice stry

080103800

RJ-J216

\

24(4-fiber ribbon)/ 36(6-fiber ribbon)/ 48(8-fiber ribbon)/ 72(12-fiber ribbon)/

\

\
