Low Cost Patch Cord Polishing Machine

Optical Fiber Polishing Machine
  • Optical Fiber Polishing Machine
  • Optical Fiber Polishing Machine

  • Product Orgin:

    Shenzhen China

  • Brand:

    K&M

  • Item NO.:

    KDMTOOL-16-1000

  • Shipping Port:

    shenzhen/hk

  • Payment:

    TT/WU

  • Price:

    $800/Pcs

  • Market Price:

    $1200

  • Price Range:

    50-100/800$

  • Color:

    optional

  • Lead Time:

    7 days
Contact Now
  • Features & Benefits

Low Cost Patch Cord Making Machine/ Optical Fiber Polishing Machine



- This Square Pressure Fiber Optic Polishing Machine strength controlled by four angle, thus the pressure is more precise to control and the final products has higher precision.
- For PC terminations above 95% could pass 3D interferometer test, while for APC terminations this rate keep 90%.
- Each polishing jig for this machine is available as LC,SC,ST, FC, MTRJ,E2000 PC connector as well as angle polishing.
- May process each kind of standard fiber optic connectors, such as FC/UPC/APC,SC/UPC/APC, ST/UPC/APC, LC/UPC/APC, ,MU/UPC/APC, MTRJ,E2000/UPC/APC etc.



- Convenience for adjusting pressure, unloading and replacing jigs.
- Excellent connector and face polishing quality, the percentage of products sent back for repair is very low.
- Save material and low cost for grinding.
- Easy to use and stable.
- Display grinding speed which can be adjusted any time.
- Control the direction with pro and con, convenience for Adjustment.
- Toothed gearing, more stable and deep-set.



Specifications:

Type:                            High Volume, Installation
Pressure Source:            Coil Spring
Polishing Capacity (max): 20 connectors for FC/SC/ST and 24 connectors for LC/MU
Dimensions:                   390*310*370mm
Weight:                        27 kgs
Input Voltage:               100-120VAC, 50/60Hz or 220-240VAC, 50/60Hz
Applicatrion:     φ2.5mm PC, APC  /  φ1.25mm PC, APC  /  MT, mini-MT.



Polishing jig for Square pressure polishing machine:



P/N

Description

LC/P-24

24 position LC/PC Connector housing polishing jig

LC/P-40

40 position LC/PC Connector housing polishing jig

SC/P-20

20 position SC/PC Connector housing polishing jig

SC/P-24

24 position SC/PC Connector housing polishing jig

FC/P-20

20 position FC/PC Connector housing polishing jig

FC/P-24

24 position FC/PC Connector housing polishing jig

ST/P-20

20 position ST/PC Connector housing polishing jig

ST/P-24

24 position ST/PC Connector housing polishing jig

MU/P-24

24 position MU/PC Connector housing polishing jig

MU/P-40

40 position MU/PC Connector housing polishing jig

LC/A-20

20 position LC/APC Connector housing polishing jig

SC/A-18

18 position SC/APC Connector housing polishing jig

FC/A-18

18 position FC/APC Connector housing polishing jig

MJ-18

18 position MTRJ connector polishing jig

MP-18

18 position MPO connector polishing jig

125/P-20

20 position 1.25mm PC ferrule polishing jig

125/A-20

20 position 1.25mm APC ferrule polishing jig

250/P-18

18 position 2.5mm PC ferrule polishing jig

250/A-18

18 position 2.5mm APC ferrule polishing jig
