100 Position Fiber Connector Heat Oven

- The fiber optical curing oven suits in the fiber optic connector Manufacturer, uses in heating up each kind of optical fiber connector.

- HW-1050 fiber connnector heat oven are dedicated to heating Ceramic Ferrule 48 port and heating connector 100 port
- fiber optical curing oven's temperature and the time establishes freely, the temperature control precision is high, may reach 1degree. And control the heating time by designation. The fiber optical curing oven easy to use and dependable.
- Applicaqtions: Multimode and Single mode
- Temperature control(0℃-300℃) and "Power On" indicator
- Temperature Stability: +/- 3℃
- Time to read 200℃: ~8 minutes
- Available in AC110V or AC220V
- Easy to use

Optic Fiber Heat Oven
  • Optic Fiber Heat Oven
  • Optic Fiber Heat Oven

  • Product Orgin:

    Shenzhen China

  • Brand:

    K&M

  • Item NO.:

    KDMTOOLS-16-0009

  • Shipping Port:

    shenzhen/hk

  • Payment:

    TT/WU

  • Price:

    $230/Pcs

  • Market Price:

    $340

  • Price Range:

    10-50/230$

  • Color:

    as pic

  • Lead Time:

    7 days
Contact Now
  • Features & Benefits

- The fiber optical curing oven suits in the fiber optic connector Manufacturer, uses in heating up each kind of optical fiber connector.

- HW-1050 fiber connnector heat oven are dedicated to heating Ceramic Ferrule 48 port and heating connector 100 port
- fiber optical curing oven's temperature and the time establishes freely, the temperature control precision is high, may reach 1degree. And control the heating time by designation. The fiber optical curing oven easy to use and dependable.
  - Applicaqtions: Multimode and Single mode
- Temperature control(0℃-300℃) and "Power On" indicator
- Temperature Stability: +/- 3℃
- Time to read 200℃: ~8 minutes
- Available in AC110V or AC220V
- Easy to use

Specifications:

1

Technical parameters

Specification

2

Heating Temperature

40-200degrees

3

Dimensions

400*320*150mm

4

Weight

7.5kgs

5

Input Voltage

100-120VAC/200-240VAC

6

Power Consumption

800W

7

Automatic

Yes

8

Making Method of Parison

PLD

9

Type

Full-Electric Controlled

10

Warm up Time(Apporox)

About 15min

11

Type of production

1.25mm, 2.5mm, SC/FC/ST/LC/

MPO/MTRJ all kinds of connectors

12

Capacity

100connectors

13

Material

Stainless Steel

14

Outer Case

Baking Paint for Metal

15

Style

Horizontal
